The LYNX® 5:1 HD series pump is perfect for medium volume users requiring an economy unit for roll-around synthetics, gear oil and standard mineral oil dispense packages. This pump can also be used for small to medium shops suppling overhead hose reels with a maximum overall flow rate of 5" gpm.
Unit of Measure

Financing

Approve Payments

 N/A Finance with Approve Payments

Specifications

Manufacturer

 N/A Balcrank

Brands

 N/A Balcrank

Model

 N/A LYNX® 5:1 HD Pump

Acceptable Mediums

 N/A Based Lubricants Gear Oil Hydraulic Fluid Synthetic and Mineral Transmission Fluid

Ratio

 N/A 5:1

Maximum Fluid Stall Pressure at 150 Pound Per Square Inch (psi) (10 Bar) Pressure

 N/A 725 psi50 bar

Effective Air Piston Diameter

 N/A 3 in80 mm
Free Flow Pump Delivery1 N/A 24 gpm90.85 L/min

Warning

 N/A Do not use any LYNX® series products with flammable fluids.

Verify fluid compatibility with MSDS sheets.

Technical Data

Operating Air Pressure

 N/A 60 to 145 psi4 to 10 bar

Efficiency

 N/A 20 cycles/gal5.28 cycles/liter

Air Consumption at 100 Pounds per Square Inch (psi) (7 bar) Pressure and 3 Gallons per Minute (gal/min) (11 Liters per Minute (l/min)) Flow

 N/A 18.80 scfm

Air Inlet Size

 N/A 1/4 in

Air Inlet Thread Type

 N/A National Pipe Tapered (NPT) Female

Fluid Inlet Size

 N/A 1 in

Fluid Inlet Port Thread Type

 N/A National Pipe Tapered (NPT) Female

Fluid Outlet Size

 N/A 3/4 in

Fluid Outlet Port Thread Type

 N/A National Pipe Tapered (NPT) Female

Wetted Materials

 N/A Aluminum Buna-N™ Polyurethane Steel Zamak

Service Bulletin

 N/A SB 1128

Dimensions

Dimension A

 N/A 19-11/16 in500 mm

Dimension B

 N/A 10-5/8 in270 mm

Dimension C

 N/A 2 in50 mm

Dimension D

 N/A 9-1/16 in230 mm

Applications

Applications

 N/A
  • Small to medium sized tank packages
  • Low to medium volume maintenance shops
  • Small car dealerships
  • Quick lubes
  • Roll-around gear oil packages

Note

Note

 N/A Thermal expansion of the fluid in a distribution system can cause an increase in system pressure that can damage lubrication system components. Use pressure relief valve kit included with this pump.

Contact Balcrank for specific system design performance and technical data.

Product specifications are subject to change without prior notice.
  • 1 SAE 10W30 oil, 68 ºF (20 ºC), 150 psi (10 bar) Air Pressure
