Republic offers the VRT series of dry-running rotary vane vacuum pumps and are ideally suited for oil free applications. They are single stage, air-cooled and direct driven for continuous operation. The design is one of the most reliable and simplest vacuum pumps available. These rugged pumps are simple to install and easy to service and maintain. The smaller pumps come with a motor integrated, while the larger pumps are available with or without motor. These pumps have a displacement ranging from 5 to 176 CFM (10 to 300 m3/hr) and a maximum vacuum of 150 torr.
The VRT series is used in a variety of industries such as vacuum lifting, woodworking, environmental applications electronics, packaging, conveying, robotics, medical vacuum/central vacuum, and printing.
The VRT series is used in a variety of industries such as vacuum lifting, woodworking, environmental applications electronics, packaging, conveying, robotics, medical vacuum/central vacuum, and printing.
Unit of Measure
Specifications
Model |
N/A VRT |
Displacement for 50 Hertz (Hz) Frequency |
N/A 9 ft³/min16 m³/h |
Displacement for 60 Hertz (Hz) Frequency |
N/A 11 ft³/min19 m³/h |
Maximum Ultimate Vacuum |
N/A 25.5 inHg112.5 Torr150 bar |
Noise Level for 50 Hertz (Hz) Frequency |
N/A 61 dB |
Noise Level for 60 Hertz (Hz) Frequency |
N/A 64 dB |
Weight |
N/A 48.5 lb22 kg |
Voltage at 50 Hertz (Hz) Frequency and 3 Phase |
N/A 175 to 260 V300 to 450 V |
Voltage at 60 Hertz (Hz) Frequency and 3 Phase |
N/A 202 to 300 V350 to 520 V |
Voltage at 50 Hertz (Hz) Frequency and 1 Phase |
N/A 230 V |
Voltage at 60 Hertz (Hz) Frequency and 1 Phase |
N/A 230 V |
Motor Output at 50 Hertz (Hz) Frequency |
N/A 0.55 kW |
Motor Output at 60 Hertz (Hz) Frequency |
N/A 0.88 hp |
Speed at 50 Hertz (Hz) Frequency |
N/A 1420 rpm |
Speed at 60 Hertz (Hz) Frequency |
N/A 1700 rpm |
Dimensions
Dimension a |
N/A 8.1 in205 mm |
Dimension b |
N/A 5.0 in128 mm |
Dimension c |
N/A 0.6 in15 mm |
Dimension c5 |
N/A 0.1 in3 mm |
Dimension d1 |
N/A 0.5 in |
Dimension e |
N/A 1.4 in35 mm |
Dimension f |
N/A 9.6 in244 mm |
Dimension f1 |
N/A 6.1 in156 mm |
Dimension g |
N/A 8.9 in225 mm |
Dimension g1 |
N/A 4.0 in102 mm |
Dimension g2 |
N/A 4.0 in102 mm |
Dimension h |
N/A 4.1 in105 mm |
Dimension h1 |
N/A 7.2 in183 mm |
Dimension h3 |
N/A 7.2 in183 mm |
Dimension h4 |
N/A 7.9 in201 mm |
Dimension h5 |
N/A 8.2 in208 mm |
Dimension i |
N/A 2.8 in70 mm |
Dimension k |
N/A 16.3 in415 mm |
Dimension k1 |
N/A 17.9 in454 mm |
Dimension o |
N/A 11.4 in289 mm |
Dimension q |
N/A 6.0 in152 mm |
Dimension s |
N/A 0.3 in7 mm |
