Item # |
Nominal Capacity |
Outside Diameter (O.D) |
HT |
Maximum Allowable Working Pressure (MAWP) |
T.W. |
TL |
Dimension F |
Web Price |
Add To Cart/Request Quote |
|---|---|---|---|---|---|---|---|---|---|
| 302439 302439/Asset/a1266.jpg | Nominal Capacity N/A 660 gal | Outside Diameter (O.D) N/A 42.00 in | HT N/A 125.00 in | Maximum Allowable Working Pressure (MAWP) N/A 165 psi | T.W. N/A 1365 | TL N/A 117.00 in | Dimension F N/A 14.00 in | Quote |
Add To Cart
Request Quote |
| 302440 302440/Asset/a1266.jpg | Nominal Capacity N/A 660 gal | Outside Diameter (O.D) N/A 42.00 in | HT N/A 125.00 in | Maximum Allowable Working Pressure (MAWP) N/A 200 psi | T.W. N/A 1570 | TL N/A 117.00 in | Dimension F N/A 14.00 in | Quote |
Add To Cart
Request Quote |
| 302441 302441/Asset/a1266.jpg | Nominal Capacity N/A 660 gal | Outside Diameter (O.D) N/A 42.00 in | HT N/A 125.00 in | Maximum Allowable Working Pressure (MAWP) N/A 300 psi | T.W. N/A 1964 | TL N/A 117.00 in | Dimension F N/A 14.00 in | Quote |
Add To Cart
Request Quote |
| 302443 302443/Asset/a1266.jpg | Nominal Capacity N/A 1060 gal | Outside Diameter (O.D) N/A 48.00 in | HT N/A 152.00 in | Maximum Allowable Working Pressure (MAWP) N/A 165 psi | T.W. N/A 1780 | TL N/A 144.00 in | Dimension F N/A 18.00 in | Quote |
Add To Cart
Request Quote |
| 302444 302444/Asset/a1266.jpg | Nominal Capacity N/A 1060 gal | Outside Diameter (O.D) N/A 48.00 in | HT N/A 152.00 in | Maximum Allowable Working Pressure (MAWP) N/A 200 psi | T.W. N/A 1780 | TL N/A 144.00 in | Dimension F N/A 18.00 in | Quote |
Add To Cart
Request Quote |
| 302446 302446/Asset/a1266.jpg | Nominal Capacity N/A 1550 gal | Outside Diameter (O.D) N/A 54.00 in | HT N/A 174.00 in | Maximum Allowable Working Pressure (MAWP) N/A 165 psi | T.W. N/A 2580 | TL N/A 166.00 in | Dimension F N/A 18.00 in | Quote |
Add To Cart
Request Quote |
| 302447 302447/Asset/a1266.jpg | Nominal Capacity N/A 1550 gal | Outside Diameter (O.D) N/A 54.00 in | HT N/A 174.00 in | Maximum Allowable Working Pressure (MAWP) N/A 200 psi | T.W. N/A 2700 | TL N/A 166.00 in | Dimension F N/A 18.00 in | Quote |
Add To Cart
Request Quote |
| 302449 302449/Asset/a1266.jpg | Nominal Capacity N/A 2200 gal | Outside Diameter (O.D) N/A 60.00 in | HT N/A 198.00 in | Maximum Allowable Working Pressure (MAWP) N/A 165 psi | T.W. N/A 3535 | TL N/A 190.00 in | Dimension F N/A 20.00 in | Quote |
Add To Cart
Request Quote |
| 302450 302450/Asset/a1266.jpg | Nominal Capacity N/A 2200 gal | Outside Diameter (O.D) N/A 60.00 in | HT N/A 198.00 in | Maximum Allowable Working Pressure (MAWP) N/A 200 psi | T.W. N/A 4100 | TL N/A 190.00 in | Dimension F N/A 20.00 in | Quote |
Add To Cart
Request Quote |
| 302452 302452/Asset/a1266.jpg | Nominal Capacity N/A 2560 gal | Outside Diameter (O.D) N/A 60.00 in | HT N/A 228.00 in | Maximum Allowable Working Pressure (MAWP) N/A 165 psi | T.W. N/A 3750 | TL N/A 220.00 in | Dimension F N/A 20.00 in | Quote |
Add To Cart
Request Quote |
| 302453 302453/Asset/a1266.jpg | Nominal Capacity N/A 2560 gal | Outside Diameter (O.D) N/A 60.00 in | HT N/A 228.00 in | Maximum Allowable Working Pressure (MAWP) N/A 200 psi | T.W. N/A 4375 | TL N/A 220.00 in | Dimension F N/A 20.00 in | Quote |
Add To Cart
Request Quote |
| 302455 302455/Asset/a1266.jpg | Nominal Capacity N/A 3000 gal | Outside Diameter (O.D) N/A 66.00 in | HT N/A 222.00 in | Maximum Allowable Working Pressure (MAWP) N/A 165 psi | T.W. N/A 5700 | TL N/A 214.00 in | Dimension F N/A 22.00 in | Quote |
Add To Cart
Request Quote |
| 302457 302457/Asset/a1266.jpg | Nominal Capacity N/A 3800 gal | Outside Diameter (O.D) N/A 72.00 in | HT N/A 236.00 in | Maximum Allowable Working Pressure (MAWP) N/A 165 psi | T.W. N/A 6800 | TL N/A 228.00 in | Dimension F N/A 24.00 in | Quote |
Add To Cart
Request Quote |
| 302459 302459/Asset/a1266.jpg | Nominal Capacity N/A 5000 gal | Outside Diameter (O.D) N/A 84.00 in | HT N/A 240.00 in | Maximum Allowable Working Pressure (MAWP) N/A 165 psi | T.W. N/A 10500 | TL N/A 232.00 in | Dimension F N/A 28.00 in | Quote |
Add To Cart
Request Quote |
